BB3 two channel kit assembly instructions

BB3 two channel kit assembly instructions

A BB3 starter kit and two full-featured DCP405 single-channel (40 V, 5 A) peripheral power modules, including an AC/DC power module for each. A two-channel programmable power source with advanced features: remote sensing, remote programming, a down-programmer, and additional OVP (with crowbar).
Enclosure & Bare Boards kit assembly instructions

Enclosure & Bare Boards kit assembly instructions

A BB3 enclosure kit with a wire harness, nuts and bolts for the three core modules, a 4.3″ TFT touchscreen display, an encoder knob, and an 80 mm fan. Includes a set of bare PCBs for building the three core modules (AUX-PS, MCU STM32F7, and BP3C DIB 3-slot backplane) as well as PCBs for building one DCM220 two DCP405 single-channel power modules.
